| Size: | 140*140*45mm |
| Motor wires: | 100% pure copper motor wires |
| Bearing: | Ball |
| Weight: | 850g |
| Safety: | Impedance Protected |
Item code: AC 14045
Housing: Aluminum Alloy, Painted Black
Impeller: Thermoplastic PBT, UL94V-0
Lead Wire: UL 1007 AWG#24,
Termination: Lead wire, no connector
Operating Temperature: -10℃ to +70℃ for Sleeve Type
-20℃ to +80℃ for Ball Type
| Model | Bearing System | Rated Voltage | Frequency | Rated Current | Rated Input Power | Rated Speed | Air Flow | Air Pressure | Noise Level | |
| Ball | Sleeve | V AC | Hz | Amp | Watt | RPM | CFM | MmH2O | dBA | |
| AM14045H1 | √ | 120V | 50/60 | 0.35 | 35 | 2800/3400 | 176/209 | 25/28 | 48/56 | |
| AM14045H2 | √ | 230V | 50/60 | 0.18 | 35 | 2800/3400 | 176/209 | 25/28 | 48/56 | |
| AM14045M1 | √ | 120V | 50/60 | 0.28 | 28 | 2400/2800 | 156/182 | 25/28 | 44/50 | |
| AM14045M2 | √ | 230V | 50/60 | 0.14 | 28 | 2400/2800 | 156/182 | 25/28 | 44/50 | |
