| Size: | 60*60*56mm |
| Motor: | DC brushless fan motor |
| Bearing: | Ball |
| Weight: | 185g |
| No. of Pole: | 4 Poles |
| Rotating Direction: | Counter-Clockwise |
| Optional Function: | 1.Lock Protection |
| 2.Polarity Protection. | |
| 3.Waterproof Level |
Item code: DC6056
Housing: Thermoplastic PBT, UL94V-0
Impeller: Thermoplastic PBT, UL94V-0
Lead Wire: UL 1007 AWG#24
“+” Red,“-” Black
Optional wire: “Sensor” Yellow,“PWM” Blue
Operating Temperature: -10℃ to +70℃，35%-85%RH for Sleeve Type
-20℃ to +80℃，35%-85%RH for Ball Type
| Model | Rated Voltage | Operation Voltage | Power | Rated Current | Rated Speed | Air Flow | Air Pressure | Noise Level |
| V DC | V DC | W | A | Front(RPM)Behind | CFM | MmH2O | dBA | |
| AM6056L12B | 12.0 | 6.0-13.8 | 15.6 | 1.30 | 18000/16700 | 70.9 | 131.3 | 76 |
| AM6056M12B | 20.4 | 1.70 | 19500/18000 | 76.4 | 142.6 | 77 | ||
| AM6056H12B | 24.0 | 2.00 | 20500/18700 | 80.4 | 148.9 | 80 |
