EC 7025

Size: 70*70*25mm
Motor wires: 100% pure copper motor wires
Bearing: Ball or Sleeve
Weight: 70g
Safety: Impedance Protected
Technical characteristics

Item code: EC 7025

Housing: Thermoplastic PBT, UL94V-0

Impeller: Thermoplastic PBT, UL94V-0

Lead Wire: UL 1007 AWG#24

Termination: Lead wire, no connector

Operating Temperature: -10℃ to +70℃ for Sleeve Type
                                        -20℃ to +80℃ for Ball Type


Performance Parameter
Model Bearing System Rated Voltage Freq. Operation Voltage Rated Current Rated Power Rated Speed Air Flow Air Pressure Noise Level
  Ball Sleeve V AC Hz V AC Amp Watt RPM CFM mmH2O dBA
AM7025HEC 115/230 50/60 98-264 0.05 4 3500 27.6 3.8 33
AM7025MEC 0.04 3 3000 23.7 3.1 28
AM7025LEC 0.03 2 2500 19.7 1.9 24
