| Size: | 200*200*60mm |
| Motor: | DC brushless fan motor |
| Bearing: | Ball, Sleeve or Hydraulic |
| Weight: | 1032g |
| No. of Pole: | 4 Poles |
| Rotating Direction: | Counter-Clockwise |
| Optional Function: | 1.Lock Protection |
| 2.Auto restart | |
| 3.Waterproof Level |
Item code: DC 20060
Housing: Thermoplastic PBT, UL94V-0
Impeller: Thermoplastic PBT, UL94V-0
Lead Wire: UL 1007 AWG#24
“+” Red,“-” Black
Optional wire: “Sensor” Yellow,“PWM” Blue
Operating Temperature: -20℃ to +80℃ for Ball Type
| Model | Rated Voltage | Operation Voltage | Rated Current | Rated Speed | Air Flow | Air Pressure | Noise Level |
| V DC | V DC | A | RPM | CFM | MmH2O | dBA | |
| AM20060H12 | 12.0 | 6.0-13.2 | 3.50 | 3000 | 570.7 | 21.4 | 56 |
| AM20060M12 | 2.80 | 2500 | 493.3 | 15.2 | 50 | ||
| AM20060L12 | 2.00 | 2000 | 392.8 | 10.0 | 44 | ||
| AM20060H24 | 24.0 | 12.0-26.4 | 2.00 | 3000 | 570.7 | 21.4 | 56 |
| AM20060M24 | 1.50 | 2500 | 493.3 | 15.2 | 50 | ||
| AM20060L24 | 1.00 | 2000 | 392.8 | 10.0 | 44 | ||
| AM20060H48 | 48.0 | 24.0-52.8 | 1.20 | 3000 | 570.7 | 21.4 | 56 |
| AM20060M48 | 0.80 | 2500 | 493.3 | 15.2 | 50 | ||
| AM20060L48 | 0.50 | 2000 | 392.8 | 10.0 | 44 |
