| Size: | 40*40*10mm |
| Motor: | DC brushless fan motor |
| Bearing: | Ball, Sleeve |
| Weight: | 15g |
| No. of Pole: | 4 Poles |
| Rotating Direction: | Counter-Clockwise |
| Optional Function: | 1.Lock Protection |
| 2.Polarity Protection. | |
| 3.Waterproof Level |
Item code: DC4010
Housing: Thermoplastic PBT, UL94V-0
Impeller: Thermoplastic PBT, UL94V-0
Lead Wire: UL 1007 AWG#24
“+” Red,“-” Black
Optional wire: “Sensor” Yellow,“PWM” Blue
Operating Temperature: -10℃ to +70℃，35%-85%RH for Sleeve Type
-20℃ to +80℃，35%-85%RH for Ball Type
| Model | Rated Voltage | Operation Voltage | Power | Rated Current | Rated Speed | Air Flow | Air Pressure | Noise Level |
| V DC | V DC | W | A | RPM | CFM | MmH2O | dBA | |
| AM4010L12B(S) | 12.0 | 6.0-13.8 | 0.36 | 0.03 | 5000 | 3.93 | 0.73 | 11.0 |
| AM4010M12B(S) | 0.72 | 0.06 | 6500 | 5.11 | 1.24 | 16.7 | ||
| AM4010H12B(S) | 0.96 | 0.08 | 8000 | 6.29 | 1.88 | 21.2 | ||
| AM4010L24B(S) | 24.0 | 12.0-27.0 | 0.48 | 0.02 | 5000 | 3.93 | 0.73 | 1.0 |
| AM4010M24B(S) | 0.72 | 0.03 | 6500 | 5.11 | 1.24 | 16.7 | ||
| AM4010H24B(S) | 0.96 | 0.04 | 8000 | 6.29 | 1.88 | 21.2 |
