| Size: | 120*120*38mm |
| Motor wires: | 100% pure copper motor wires |
| Bearing: | Ball or Sleeve |
| Weight: | 350g |
| Safety: | Impedance Protected |
Item code: EC 12038 metal frame
Housing: Aluminum Alloy, Painted Black
Impeller: Thermoplastic PBT, UL94V-0
Lead Wire: UL 1007 AWG#24
Termination: Lead wire, no connector
Operating Temperature: -10℃ to +70℃ for Sleeve Type
-20℃ to +80℃ for Ball Type
| Model | Bearing System | Rated Voltage | Freq. | Operation Voltage | Rated Current | Rated Power | Rated Speed | Air Flow | Air Pressure | Noise Level | |
| Ball | Sleeve | V AC | Hz | V AC | Amp | Watt | RPM | CFM | mmH2O | dBA | |
| AM12038DEC1 | √ | 115/230 | 50/60 | 98-264 | 0.12 | 18 | 4000 | 158.5 | 15.5 | 52 | |
| AM12038HEC1 | √ | √ | 0.10 | 8 | 3000 | 110.5 | 9.7 | 45 | |||
| AM12038MEC1 | √ | √ | 0.08 | 5 | 2600 | 87.5 | 5.5 | 39 | |||
| AM12038LEC1 | √ | √ | 0.06 | 3 | 2300 | 78.6 | 5.1 | 36 | |||
