| Size: | 110*110*25mmm |
| Motor wires: | 100% pure copper motor wires |
| Bearing: | Ball or Sleeve |
| Weight: | 270g |
| Safety: | Impedance Protected |
Item code: AC 11025
Housing: Aluminum Alloy, Painted Black
Impeller: Thermoplastic PBT, UL94V-0
Lead Wire: UL 1007 AWG#24,
Termination: Lead wire, no connector
Operating Temperature: -10℃ to +70℃ for Sleeve Type
-20℃ to +80℃ for Ball Type
| Model | Bearing System | Rated Voltage | Frequency | Rated Current | Rated Input Power | Rated Speed | Air Flow | Air Pressure | Noise Level | |
| Ball | Sleeve | V AC | Hz | Amp | Watt | RPM | CFM | MmH2O | dBA | |
| AM11025MS1 | √ | 110-125 | 50/60 | 0.20/0.18 | 18/17 | 2000/2500 | 46/50 | 3.0/4.6 | 36/38 | |
| AM11025MB1 | √ | 110-125 | 50/60 | 0.20/0.18 | 18/17 | 2100/2600 | 46/50 | 3.3/4.8 | 36/38 | |
| AM11025MS2 | √ | 200-240 | 50/60 | 0.10/0.09 | 18/17 | 2000/2500 | 46/50 | 3.0/4.6 | 36/38 | |
| AM11025MB2 | √ | 200-240 | 50/60 | 0.10/0.09 | 18/17 | 2100/2600 | 46/50 | 3.3/4.8 | 36/38 | |
