| Size： | 180*180*60mm |
| Motor wires: | 100% pure copper motor wires |
| Bearing: | Ball |
| Weight: | 1240g |
| Safety: | Impedance Protected |
Item code: AC 18060
Housing: Aluminum Alloy, Painted Black
Impeller: Thermoplastic PBT, UL94V-0
Lead Wire: UL 1007 AWG#22
Termination: Lead wire, no connector
Operating Temperature: -20℃ to +80℃ for Ball Type
| Model | Bearing System | Rated Voltage | Frequency | Rated Current | Rated Input Power | Rated Speed | Air Flow | Air Pressure | Noise Level |
| V AC | Hz | Amp | Watt | RPM | CFM | MmH2O | dBA | ||
| AM18060MB1 | Ball | 100-125 | 50/60 | 0.50/0.52 | 55/50 | 2600/3000 | 345/395 | 16/22 | 63/68 |
| AM18060MB2 | Ball | 200-240 | 50/60 | 0.45/0.41 | 55/50 | 2600/3000 | 345/395 | 16/22 | 63/68 |
| AM18060MB3 | Ball | 380-420 | 50/60 | 0.34/0.31 | 55/50 | 2600/3000 | 345/395 | 16/22 | 63/68 |
