| Size: | Φ150*38mm |
| Motor: | DC brushless fan motor |
| Bearing: | Ball |
| Weight: | 283g |
| No. of Pole: | 4 Poles |
| Rotating Direction: | Counter-Clockwise |
| Optional Function: | 1.Lock Protection |
| 2.Auto restart | |
| 3.Waterproof Level |
Item code: DC15038
Housing: Thermoplastic PBT, UL94V-0
Impeller: Thermoplastic PBT, UL94V-0
Lead Wire: UL 1007 AWG#24
“+” Red,“-” Black
Available Option: “Sensor” Yellow,“PWM” Blue
Operating Temperature: -10℃ to +70℃，35%-85%RH for Sleeve Type
-20℃ to +80℃，35%-85%RH for Ball Type
| Model | Rated Voltage | Operation Voltage | Power | Rated Current | Rated Speed | Air Flow | Air Pressure | Noise Level |
| V DC | V DC | W | A | RPM | CFM | MmH2O | dBA | |
| AM15038L24B | 24.0 | 12.0-27.0 | 3.6 | 0.15 | 2000 | 121.6 | 3.8 | 42.1 |
| AM15038M24B | 7.2 | 0.30 | 2500 | 164.8 | 6.4 | 48.0 | ||
| AM15038H24B | 12.0 | 0.50 | 3000 | 202.8 | 7.8 | 52.7 |
